New Product Release - PI15016/11




Highly Integrated, Low-power

Analog Monitoring & Control Solution

PI15016/11


PON OLT Controller





01

Description



    The PI15011 and PI15016 are highly integrated, low-power, analog monitoring and control solution with a comprehensive set of integrated TEC, Buck and Inverting DC-DC regulators. A wide variety of optical transceiver controller applications are supported without need of external circuitry, thereby minimizing cost and PCB area.


      The PI15011 is optimized for PON OLT and other EAM based modules. It has a 12-bit current output digital-to-analog converter (IDAC) for the laser bias current with the output power feedback loop. provided from the MPD current to a TIA and 12-bit, 250KSPS analog-to-digital converter (ADC). The IDAC supports a full-scale output range of 150mA with very low headroom. The buck dc-dc is used to supply the IDAC supply voltage and is programmable to optimize power dissipation.


      The EAM bias is supplied through a 12-bit negative voltage output DAC (VDAC). Current from this DAC can be monitored through the ADC. The VDAC is capable or sourcing and sinking up to 60mA. The inverting dc-dc converter is used to supply this VDAC.


     A second IDAC can supply up to 250mA in applications that require SOA bias.


    The ADC and incorporate a low-latency window comparator, making it suitable solutions for monitor photo diode (MPD), received signal strength indicator (RSSI) and loss-of- signal (LOS) detection. The ADC is also capable of measuring the voltage at the IDAC pins as well as the current being sourced or sunk by the VDACs, thus enabling power monitoring of these outputs.


    An integrated TEC controller is provided with digital set-point and PID control along with monitor and alarm functions.


   The PI15016 includes all the features of the PI15011 but also adds support for dual SOA’s and dual LD/EAM modules through additional IDACs and VDACs. Two of the IDACs can support 250mA for SOA bias.



02

Features



12-bit Current Output DACs (IDACs)

One 150mA and one 150 / 250mA (PI15011)

Two 150mA and two 150 / 250mA (PI15016)



12-bit Voltage Output DACs (VDACs)

One Negative, Two positive -PI15011

Two Negative, Two positive -PI15016

Configurable ranges: VREF or 2*VREF

±60 mA drive capability



Multi-channel, 12-bit, 250KSPS SAR ADC

Four external voltage inputs

TIA inputs with programmable negative bias

IDAC voltage monitor channels

VDAC current monitor channels

Programmable sequencer

Programmable out-of-range alarms



Internal Voltage Reference



Internal Temperature Sensor with Fault Alarm



Buck Regulator

Output voltage range of 1.2V to 2.5V

Output current: 1.0A

12-bit set point

92% efficiency at 0.6A



Inverting Regulator

Output voltage range of -2.0V to -4.5V

Output current: 300mA

5-bit set point

81% efficiency at 200mA



TEC Controller

Single inductor

Output current: ±1.5A

12-bit set point

90% peak efficiency



SPI & I2C Interface: 1.8V or 3.3V Operation



Reset, Disable, Interrupt & LOS functions




03

Applications



     The PI15011 and PI15016 provide a complete control and PMIC solution for a wide range of Fiber Optic Modules:


         – 10G Combo PON OLT

         – 25G Combo PON OLT

         – 50G Combo PON OLT

         – Tunable modules

         – EAM based modules

         – EAM+SOA based modules




04

Order Information

DEVICE

DEVICE

PACKAGE

SHIPMENT

PACKAGING

PI15011-W1R

WLCSP

Tape and reel

PI15016-W1R

WLCSP

Tape and reel
